Real-Time Display 100 fps (PAL) / 120 fps (NTSC) Display Rate
-
MPEG-4 compression, Display Resolution: 704 x 576 (PAL) / 704 X 480 (NTSC)
-
Recording Rate:
-
Up to 100fps@704 x 576(PAL) / Up to 120fps@704 x 480(NTSC) (4CIF)
-
Up to 200fps@704 x 288(PAL) / Up to 240fps@704 x 240(NTSC) (2CIF)
-
Up to 225fps@352 x 288(PAL) / Up to 270fps@352 x 240(NTSC) (CIF)
-
Various Recording Mode (Manuall / Schedule / Event)
-
User Friendly Setup & Operation, On Screen Display by Stylish Icon
-
4 Channels BNC Video In, 2 Channels BNC Video Out, VGA Output & 4CH Loop Out
-
Display Multiscreen 1/ 4 / 9, OSD (Multi-Language)
-
4 Channels Audio Input, 1 Channels Audio Output
-
4 Channels Sensor Input, 2 Channes Alarm Output
-
2 Sata HDDs bay internal capacity, Easy back-up with 2 USB ports and DVD+RW
-
Network Protocol: TCP/IP, DHCP, SMTP
-
Powerful Remote Monitoring With SVR Manager Program
-
Built-in Web-server, Support CMS Software (SNM-128S/P)
-
Integrated Network Multi-view, Multi-users Remote Viewing
-
Various Input controllers Including Remote Control and Keyboard Controller (SCC-3100A)
-
Serial Interface: RS-232C, RS-485 / 422 (RJ-45)
-
100-240V AC, Power Consumption Max 65W With 1 HDD
-
Dimension: 350mm x 88mm x 401.3mm, Weight 8.9Kg, above price is excluding Harddisk
