4 CH BNC Video Input, 1 CH Video Output, 1CH VGA Output
-
H.264 Compression, Real Time Display 120fps Display Rate
-
Display Resolution: 720 x 576 (PAL) / 720 x 480 (NTSC)
-
Recording Resolution:
-
30IPS 704 x 576 (PAL) / 704 x 480 (NTSC)
-
60IPS 720 x 288 (PAL) / 720 x 240 (NTSC)
-
CIF: 120fps 352 x 288 (PAL) / 352 x 240 (NTSC)
-
Manual / Schedule / Alarm / Motion Recording
-
4 CH Audio Input 1 CH Audio Output, 4 CH Alarm Input 1Ch Alarm Output
-
Support One Unit Sata Harddisk (Max 1 TB)
-
Support PTZ Control, Support Video Mobile Phone Surveillance Software
-
Support Network Remote Recording & Back-up, Pendrive Back up (USB 2.0)
-
Support IE ICP/IP, PPPoE, DHCP, DDNS
-
Remote Access & Surveillance with IE Browser, CMS Software Video Mobile Phone Surveillance Software
-
Watch Dog Feature, Video Loss Detection, Power Loss Recovery Function
-
IR Remote Controller & USB Mouse Control
-
Dimension: 315mm x 224m x 52mm, Weight 1.5 Kg
